HACH Orbisphere 410K Controller, 1 Channel, LDO Luminescent Dissolved Oxygen (O₂), wall mount, 10-30 VDC, 4-20 mA, RS485 PN.410K/W2C00000
HACH Orbisphere 410K Controller, 1 Channel, LDO Luminescent Dissolved Oxygen (O₂), wall mount, 10-30 VDC, 4-20 mA, RS485 PN.410K/W2C00000
无法加载取货服务可用情况
* Please consult before ordering
Precise, Powerful Process Monitoring
The Hach Orbisphere 410 Mono-Channel Controller is a high accuracy instrument designed for the measurement of oxygen (LDO or EC), ozone (EC) or carbon dioxide (TC) by connecting the according Orbisphere high quality sensor.
Depending on which version is best suited for your process, the Hach Orbisphere 410 controllers are available as wall-mount or panel-mount version for process and laboratory analysis.
The Data Management system keeps you up to date with important information such as trace level measurement data, operator actions and calibration details with the security of a software password protected, reducing the risk of errors in operation or configuration.
Please do not hesitate to contact us to define the best configuration for your application.
Benefits
Easy to use, intuitive software using clear, full colour touch-screen
All functions of Orbisphere 410 instruments are accessed through the colour touch-screen. This screen acts as display and keyboard.
Internal diagnostics and reminders for maintenance and calibration
To ensure continuous high performance and simplify maintenance, Orbisphere 410 instruments offer a number of diagnostic features: A notification that calibration is due ensures QC procedural compliance, a notification that a sensor service is due ensures optimal preventative maintenance planning. The sensor service diagnostics minimises downtime, and system alarms transmitted through analogue output provide continuous status indication.
Easy to use and reliable
Orbisphere 410 instruments are designed for ease of use. After simple installation, the system is measuring your process in minutes. Simple menus allow you to rapidly create a specific configuration for the instrument. The main measurement window continuously displays real time process readings, graphed sensor trends (user selectable from last 1 minute to last 1 hour), alarm limits, temperature and event occurrence.
Multiple communication options including USB and Profibus
Digital communication uses industry standard protocols including Profibus and USB in addition to traditional analogue outputs and alarm relays. These may all be configured in terms of function, content and behaviour.
Data storage
Data storage of up to 10000 measurements, last 1000 operator actions and details of last 50 calibrations.
Specifications
Technical Attributes
| Analog Outputs | 3 smart 0/4-20 mA (500 ohms), programmable as linear or tri-liniear, configurable to send diagnostics information |
| Communication | RS485 |
| Communication Capabilities | 3 x 0/4-20 mA; RS485; Ethernet |
| Compatible Instruments | Channel 1: K1100 |
| Compliance Certifications | EMC: EN61326-1:2006 CE: EN61010-1:2010 ETL, conforming to UL 61010-1 and CSA 22.2 No. 61010-1 |
| Controller | 410, Mono-channel |
| Data Storage | Rolling buffer or store once mode for up to 1000 measurements and 1000 operator actions Holds calibration records for last 50 calibrations |
| Dimensions (H x W x D) | 236.5 mm x 250 mm x 160 mm |
| Display | Colour TFT touch-screen display |
| Measurements | Resolution, accuracy and response time are determined by sensor |
| Mounting | Wall |
| Operating Conditions | 0 - 95 % non-condensing relative humidity |
| Operating Temperature Range | -5 - 50 °C |
| Parameter | Oxygen LDO sensor K1100 (power and steam) |
| Password Protection | 5 levels of authorised access to configuration and data management |
| Power | 10 to 30 VDC - 30W |
| Power Requirements (Voltage) | 10 - 30 V DC |
| Relays | 3 measurement alarm relays (2A to 30 VAC or 0.5 A to 50 VDC); configurable to send diagnostics information 1 system alarm relay (2 A to 30 VAC or 0.5 A to 50 VDC) |
| Units | Gas concentration: Configurable for gas or liquid phase with multiple unit options Pressure: External and barometric pressure with multiple unit options Temperature: Sample temperature with unit options (K, °C, °F) |
| User Interface | Touch screen panel displays: concentration, trend graph, diagnostics, alarm status, historical data |
| Warranty | 12 months |
| Weight | 4.25 kg |
| What's included? | 410 controller and manual only. K1100 Sensor and cable, flow-chamber or process connection, must be ordered separately. |
